· Suitable for load capacity400-1500kg, compatible with positive electrode / Negative electrode coil transportation
· Single unit operation efficiency12Roll/h, meeting the full production rhythm of the production line
· X/Y/Z · Special nylon walking wheels, wear-resistant and quiet, long-term stable operation
· Machine positioning accuracy* * ± 1mm * *, manual jog accuracy 1~2mm
· Visual + Ultrasonic dual verification, automatic alignment deviation≤2mm
· 0~360 °Pneumatic slip ring rotation, flexible adaptation for multi station docking
· Weighing sensor linear Z Axis deflection compensation to prevent material sinking during material extraction
· SupportsFully automatic / Wired Remote ControlDual Mode Switching
· OPC UA Protocol docking with logistics central control, can be integrated with AGVSeamless collaboration of winding machines
· Modular DFMA Design, quick connection of module aviation plugs, efficient installation and debugging
· 10 inch graded permission HMI, with visible parameters, traceable alarms, and traceable operations
· Suitable for Class 10000 clean workshops, low dust drag chain, fully sealed dust-proof design
· Non metallic material contact surface is used / · Easy to clean without dead corners, fully wrapped transmission components, strict control of particles and foreign objects
· Non metallic material contact surface is used / · Easy to clean without dead corners, fully wrapped transmission components, strict control of particles and foreign objects
